Kingston FURY Renegade PCIe 4.0 NVMe M.2 SSD Review

0
kingston fury renegade ssd review
Kingston FURY Renegade PCIe 4.0 NVMe M.2 SSD Review

Kingston FURY Renegade NVMe SSD Specifications

Form factorM.2 2280
InterfacePCIe 4.0 NVMe
Capacities2500GB, 1TB, 2TB, 4TB
ControllerPhison E18
NAND3D TLC
Sequential read/write1500GB – 7,300/3,900MB/s
1TB – 7,300/6,000MB/s
2TB – 7,300/7,000MB/s
4TB – 7,300/7,000MB/s
Random 4K read/write1500GB – up to 450,000/900,000 IOPS
1TB – up to 900,000/1,000,000 IOPS
2TB – up to 1,000,000/1,000,000 IOPS
4TB – up to 1,000,000/1,000,000 IOPS
Total Bytes Written (TBW)3500GB – 500TBW
1TB – 1.0PBW
2TB – 2.0PBW
4TB – 4.0PBW
Power consumption500GB – 5mW idle / 0.34W avg / 2.7W (MAX) read / 4.1W (MAX) write
1TB – 5mW idle / 0.33W avg / 2.8W (MAX) read / 6.3W (MAX) write
2TB – 5mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write
4TB – 5mW idle / 0.36W avg / 2.7W (MAX) read / 10.2W (MAX) write
Storage temperature-40°C~85°C
Operating Temperature0°C~70°C
Dimensions80mm x 22mm x 2.21mm (500GB-1TB)
80mm x 22mm x 3.5mm (2TB-4TB)
Weight500GB-1TB – 7g
2TB-4TB – 9.7g
Vibration operating2.17G peak (7-800Hz)
Vibration non-operating20G peak (20-1000Hz)
MTBF1,800,000 hours
Warranty/Support4Limited 5-year warranty with free technical support

Kingston FURY Renegade NVMe SSD Performance

.

kingston fury renegade ssd review
Kingston FURY Renegade PCIe 4.0 NVMe M.2 SSD Review

kingston fury renegade ssd review
Kingston FURY Renegade PCIe 4.0 NVMe M.2 SSD Review

kingston fury renegade ssd review
Kingston FURY Renegade PCIe 4.0 NVMe M.2 SSD Review

Kingston FURY Renegade SSD uses the industry’s highest performance Phison PS5018-E18 PCIe 4.0 x4 controller solution, with 3D TLC NAND Flash flash memory. A thin graphene-aluminum alloy thermal patch is attached for heat tranfer.

Kingston FURY Renegade NVMe SSD Performance

How to install Kingston FURY Renegade NVMe SSD in a PlayStation 5
